Includes a USB-C to Lightning cable Connect the BTR5 2021 to your iPhone/iPad/iPod via this cable to enjoy high-quality music.
Features
High-performance DAC ES9219C*2
Qualcomm CSR8675
XMOSXUF208 USB
MQA Support
3.5mm+2.5mm headphone outs
FiiO Music app control
Bluetooth 5.0
Driver-free mode (Switch mode)
In-vehicle mode
NFC
Built-in omnidirectional microphone
cVc 8.0 noise cancellation
Support external microphone of CTIA cable
Support Bluetooth call
Specs
DAC chip: ES9219C*2
USB decoding chip: XMOS XUF208
Audio Input: Bluetooth connection
Supported Audio Formats: AAC/SBC/aptX/aptX LL/ aptX HD/LDAC
Single-ended Headphone Output: 3.5 mm stereo port
Balanced Headphone Output: 2.5mm port
USB Port: Type-C
Recommended headphone impedance: 16 - 100Ω (PO), 16 - 150Ω (BAL)
Channel Balance: ≤0.1 dB
Gain: Supported (High/Low)
Battery Capacity: 550 mAh
Battery Life: 9h (3.5mm output), 7h (2.5mm output)
Charging Time: 1.5 hour
Power Input: Recommend DC 5V 500mA
Frequency Response: 20Hz - 20kHz (aptX), 20Hz - 40kHz (LDAC)
THD+N: PO＜0.003% (LDAC 1kHz 32Ω dbA), BAL＜0.002% (LDAC 1kHz 32Ω dbA)
Output Impedance: PO≤1.0Ω（32Ω loaded), BAL≤2.0Ω（32Ω loaded)
Noise Floor: PO≤2μV (32Ω dbA), BAL≤2.2μV（32Ω dbA）
SNR: PO≥118dB (32Ω dbA), BAL≥122dB(32Ω dbA)
Amplitude - PO：1.6V (32Ω/THD+N＜1%), PO: 1.8V (no loaded), BAL: 2.8V（32Ω /THD+N＜1%）, BAL: 3.6V (no loaded)
Sampling Rate Supported: up to 384kHz/32bit（USB DAC）
DSD Support (USB IN): DSD64/128/256
Dimensions: 72 x 32 x 11.1 mm
Weight: 43.7 g
Box Content
FiiO BTR5-2021 Portable High-Fidelity Bluetooth Amplifier
USB Type-C to Lightning cable
Charging cable
Back clip
USB Type-C to Type-C cable
Quick start guide
