Features

- Dolby Atmos® and MultiBeam™ surround sound

- Punchy bass without the need for a separate subwoofer

- Chromecast built-in™, AirPlay and Alexa Multi-Room Music (MRM)

- Ultra HD 4K Pass-through with Dolby Vision™

- HDMI eARC

- Automatic MultiBeam™ Calibration

- Multi-room possibilities

- Bluetooth wireless streaming

- Works with voice control

Technical Specifications

General specification

- Model No.: BAR 5.0 MULTIBEAM

- Total speaker power output (Max. @THD 1%): 250 W

- Soundbar output power (Max. @THD 1%): (5 x 50 W)

- Transducer: 5 x 48mm x 80mm racetrack drivers + 4 x 3 inches (75mm) Passive Radiators

- Power supply: 100 – 240V AC, ~ 50/60Hz

HDMI

- HDMI In: 1

- HDMI eARC: 1

- HDMI HDCP version: 2.3

Audio

- Max SPL: 92 dBA

- Frequency response: 50Hz – 20kHz

- Audio inputs: 1 Optical, Bluetooth, Chromecast, AirPlay 2, Alexa MRM, USB

USB specification

- USB charge out: Type A, USB rating: 5V DC, 0.5A

- USB Port: (*USB playback is available in US version. For other versions, USB is for Service only.)

Wireless specification

- Bluetooth® version: 4.2

- Bluetooth® profile: A2DP 1.2, AVRCP 1.5

- Bluetooth® transmitter power: <10 dBm (EIRP)

- Wi-Fi network: IEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)

- 2.4G Wi-Fi transmitter frequency range: 2412 – 2472MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)

- 2.4G Wi-Fi transmitter power: <20dBm

- 5G Wi-Fi transmitter frequency range: 5.15 – 5.35GHz, 5.470 – 5.725GHz, 5.725 – 5.825GHz

- 5G Wi-Fi transmitter power: <23dBm (EIRP)

Audio specification

- Supported formats: MP3 Codec: MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3 (USA only), Dolby Atmos, PCM

Dimension (Soundbar)

- Dimensions (W x H x D): 709.0 x 60.5 x 100.5mm / 27.9" x 2.4" x 3.9"

- Weight: 2.8kg

Dimension (Packaging)

- Dimensions: 966 x 126 x 161mm / 38.0" x 4.9" x 6.3"

- Gross Weight: 4.5kg

What’s in the box:

- 1 x Soundbar

- Remote control with 2 x batteries

- Power cords (up to 8pcs depending on region SKUs)

- 1 x HDMI cable

- 2 x L-shape wall-mount bracket with screws

- Quick start guide

- Warranty card

- Safety sheet
