Tech Specs
Output
Output power capacity 700Watts / 1.0 kVA
Max Configurable Power (Watts) 700Watts / 1.0 kVA
Nominal Output Voltage 120V
Output Voltage Distortion Less than 5%
Output Frequency (sync to mains) 50/60Hz +/- 3 Hz
Load Crest Factor up to 5 : 1
Topology Line Interactive
Waveform type Sine wave
Output Connections (6) NEMA 5-15R (Battery Backup)
Transfer Time 4ms typical : 8ms maximum
Input
Nominal Input Voltage 120V
Input frequency 50/60 Hz +/- 3 Hz (auto sensing)
Input Connections NEMA 5-15P
Input voltage range for main operations 82 – 144V
Input voltage adjustable range for mains operation 75 – 154V
Cord Length 2.44meters
Number of Power Cords 1
Batteries & Runtime
Battery type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time 3hour(s)
Expected Battery Life (years) 4-6
RBC Quantity 1
Communications & Management
Interface Port(s) SmartSlot, USB
Control panel Multi-function LCD status and control console
Audible Alarm Alarm when on battery : distinctive low battery alarm : configurable delays
Emergency Power Off (EPO) Optional
Available SmartSlot™ Interface Quantity 1
Surge Protection and Filtering
Surge energy rating 459Joules
Filtering Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Maximum Height 89mm, 8.9CM
Maximum Width 432mm, 43.2CM
Maximum Depth 457mm, 45.7CM
Rack Height 2U
Net Weight 28.18KG
Shipping weight 31.45KG
Shipping Height 251mm, 25.1CM
Shipping Width 594mm, 59.4CM
Shipping Depth 603mm, 60.3CM
Color Black
Units per Pallet 8
Environmental
Operating Temperature 0 – 40 °C
Operating Relative Humidity 0 – 95 %
Operating Elevation 0-3000meters
Storage Temperature -15 – 45 °C
Storage Relative Humidity 0 – 95 %
Storage Elevation 0-15000meters
Audible noise at 1 meter from surface of unit 45.0dBA
Online thermal dissipation 56.0BTU/hr
Conformance
Approvals CSA, FCC Part 15 Class A, UL 1778
Equipment protection policy Lifetime : $150000
Standard warranty 3 years repair or replace (excluding battery) and 2 year for battery
Sustainable Offer Status
RoHS Compliant
REACH REACH: Contains No SVHCs
PEP Available in Documentation tab
EOLI Available in Documentation tab
