แท่นชาร์จแบต DualDigital BatteryLCD CHARGER Canon NB-2L

รายละเอียดสินค้า





Features:



1. Wide range compatibility. It can charge for digital Li-ion battery with 8.4/ 12.6/ 16.8 of any capacity.

2. Intelligent control. Control MCU can automatically identify the voltage of the battery, gonging intelligent charge when being charging, and prevent overcharge.

3. Dual charging port design. It can charge two batteries at the same time.

4. Be changeable battery charger plates, suitable for most of camera/ camcorder batteries.

5. LCD display. Battery power level show, the percentage of power level and current mode.

6. Charging type is CC/CV with well reliability and high efficiency.

7. With the function of pre-charging and lithium battery 0V activation which can effectively extend battery life.



Specification:



Color: Black

Suitable for: Canon NB-2L

Input: AC 100V-240V 50/60Hz 1500mA (max) DC 12-24V 3000mA (min)

Output voltage: DC 8.4V/ 12.6V/ 16.8V

Output current : L 1000mA×1 500mA×2 H 1500mA×1 800mA×2

USB output: 5V---2100mA

Charger dimension: approx. 12.5cm×11.2cm×4cm/4.9×4.4×1.6in

Plate dimension: approx. 6.8cm×4.8cm×1.7cm/2.7×1.9×0.7in

Weight: approx. 288g



Package included:



1x Dual digital battery charger

2x Battery charger plates

1x Power Cable

1x User manual



How To Use



1. Connect the AC cable to Car charger DC input. The LCD display white light power on.

Note: The LCD charger show the precision power level and battery capacity after installing the batteries when power on.

2. Install the battery which need charging to the plate, after installing the batteries, the charger detect the load and start pre-charging, LCD graphic will blink gradually.

Note: 1. Charging the default for the low current mode.

2. Shortly push the button, can change current mode.

3. When fully power, please take out the battery, turn off the power.

4. USB can be worked with low current or no battery mode.



Caution



1. Don’t charge unmatched battery otherwise will damage battery, leak even explode and bodily injury and property damage.

2. Charger will be damaged if not using correctly.

3. It is used indoors or in car, please don’t expose it to rain or snow.

4. Please don’t disconnect or install it.

5. Avoid falling or placing heavy object on it.

6. Children should use it at the supervision of adult.

7. Working temperature keeps 0-4 degree.

8. Keep it away from heat equipment or high temperature place, and don’t expose to direct sunlight.

9. It is normal to be a little heat while charging.

10. Take out rechargeable battery when don’t use charger to charging.
