Specifications
Total # Of Inputs 10 Inputs
Mic/Line Inputs 2 Mic: 3-pin XLR
10 Line: 1/4″ TRS Phone
Stereo Line Inputs 4 Stereo: L/R Paired 1/4″ TRS Phone channels 3/4, 5/6, 7/8 and 9/10
In-Line Inputs/Returns No
AUX Sends Stereo 1/4″ TRS Phone
AUX Returns No
Inserts No
BUS (Group) Outputs Stereo Main Only: L/R 1/4″ TRS Phone
2 Trk Master I/O CD/Tape –
Input: L/R RCA Phono
Output: L/R RCA Phono
ALT I/O No
Monitor Outputs Phones: 1/4″ Stereo
EQ Section Low: 80Hz ±15dB
High: 12kHz ±15dB
Solo/Mute No
Channel Level Control Rotary Controls
Trim/Gain Control No
Phantom Power +48V Phantom
Metering Stereo: 4-segment Peak LED meters
Frequency Response 10Hz to 20kHz (-3dB)
Dynamic Range Not Specified by Manufacturer
Signal-to-Noise Ratio 110dB / 112dB A-weighted
Total Harmonic Distortion (THD) 0.005% / 0.004% A-weighted
Power Supply 13W
USA/Canada 120V~, 60Hz, MXUL5 adapter
Dimensions (HxWxD) 1.85 x 7.44 x 8.66″ (47 x 189 x 220mm)
Weight 2.31 lbs (1.05kg)


Packaging Info
Package Weight 4.85 lb
Box Dimensions (LxWxH) 13.2 x 10.5 x 4.1″
