Drive On
INNOVATIVE ALLOY/FIBRE BASS ENGINES
The 8” long throw active and 10” passive drivers are where T/7x derives its incredible speed and clean finish. A thorough revision of critical suspension components are responsible for the agility and suppleness of T/7x. The T/7x sounds louder and more powerful is expected, but few would predict it also is faster, more reactive and transparent than our prior generation, itself a paragon of virtue. Stiffer suspensions better suited to advanced duty mean not only can each driver trace minute details, but also travel farther and handle more power.

Amplifier

Tried and True Amplifiers
THE POWER BEHIND REL
We have retained our signature Class A/B amplifiers used in every generation of Serie T since 2006. Reliability is the key to happy ownership and with some 200,000 and counting of this range leading long happy lives, Serie T/x owners can feel certain of REL’s standard setting reliability. The powerful 200-watt mosfet amplifier used in the T/7x remains an icon of sound and reliability with huge reserves of current. Massive power supplies are used and small upgrades are found everywhere. New driver mosfets that open up performance and transparency and new methods for securing the toroidal transformers mean better performance and superior reliability. The best gets better.

Standby Mode switch is only included on 220V units.

Wireless

Zero Compression Wireless
UNLIMITED POSSIBILITIES
At REL, we’ve developed a sterling reputation for building the finest sounding, fastest wireless systems available in the industry. REL never rely upon digital compression as it results in thin, lifeless sound. Instead, we have perfected an (optional) Arrow™ Wireless system; so fast and dynamic we’re comfortable encouraging the use of wireless on one channel of a pair of RELs while the other channel may be connected hardwired with cable.

Specs
Specifications
TYPE
Front-firing active driver, down-firing passive

ACTIVE DRIVER SIZE & MATERIAL
8 in., 200mm long-throw, FibreAlloy™ inverted aluminium dust cap, steel chassis

PASSIVE RADIATOR SIZE & MATERIAL
10 in., 254mm long-throw, inverted dust cap

LOW FREQUENCY EXTENTION
-6dB at 30 Hz

INPUT CONNECTORS
High Level Neutrik Speakon, Low Level single RCA, LFE RCA

OUTPUT CONNECTORS
N/A

POWER OUTPUT
200 Watts (RMS)

AMPLIFIER TYPE
Class A/B

WIRELESS CAPABILITY
Arrow (Optional), Zero Compression, Single Large Scale Integrated Chip

Protection System
FULLY ELECTRONIC SET SAFE
Yes

D.C. FAULT
Yes

OUTPUT SHORT
Yes

MAINS INPUT VOLTAGE
220-240 volts, 110-120 volts for certain markets

FUSES
2 Amp semi delay 230 volts operation, 4 Amp semi delay 115 volts operation

Dimensions
W X H X D
14.0 x 12.6 x 14.3 in., (356 x 320 x 363 mm)

NET WEIGHT
38.5 lbs. (17.5 kg)

FINISH
High Gloss Black, High Gloss White, 5 coats

Supplied Accessories
MAINS LEAD
Yes

NEUTRIK SPEAKON
Yes (10 Meters Nominal)

INTERCONNECT
-

USERS MANUAL
Yes
