Features
Up to 150W per Channel at 8 Ohms
YPAO R.S.C. Multipoint Sound Calibration
4K UHD Pass-Through
HDR10, Dolby Vision, HLG Pass-Through
7 x HDMI-In / 3 x HDMI-Out with eARC
Stereo XLR Input and Pre-Output
Built-In Wi-Fi and Bluetooth
Alexa, Google Assistant, Siri Control
Apple AirPlay 2 Connectivity
Front-Panel USB Connectivity Additional Features

Spotify Connect
Pandora, Spotify, Napster, SiriusXM, TIDAL, Deezer, Qobuz, and Amazon Music HD
Third-party control driver-capable with easy IP setup and remote IP control
24 DSP programs
Dialogue Level Adjustment
Virtual Presence Speaker & Virtual Surround Back Speaker
Dialogue Lift
SILENT Cinema / Virtual Cinema DSP
Supports playback of ALAC up to 96 kHz / 24-bit, FLAC up to 384 kHz / 24-bit, and WAV/AIFF up to 384 kHz / 32-bit
Pure Direct
High-resolution Music Enhancer
YPAO Volume
Adaptive DRC (dynamic range control)
Initial volume and maximum volume setting
Audio delay (0 to 500 ms)
384 kHz / 32-bit ESS HyperStream DAC ES9026PRO and ES9007S DACs
8K UHD upscaling via a planned future update
Analog to HDMI upconversion
Video adjustment
HDMI CEC
Web browser control
Zone 4 audio output via HDMI
Zone GUI
Party Mode
Auto Power Standby
ECO Mode


Specs

Amplifier
Channels 9.2
Power Output per Channel 2-Channel Driven:
150 W at 8 Ohms / 20 Hz to 20 kHz / 0.06% THD
165 W at 8 Ohms / 1 kHz / 0.09% THD
1-Channel Driven:
185 W at 8 Ohms / 1 kHz / 0.9% THD
200 W at 6 Ohms / 1 kHz / 0.9% THD
230 W at 4 Ohms / 1 kHz / 0.9% THD
Frequency Response 10 Hz to 100 kHz +0/-3 dB (Direct, Pure Mode)
Speaker Impedance 4 to 8 Ohms
Tone Control Bass (50 Hz): ±6 dB
Treble (20 kHz): ±6 dB
Damping Factor >120
Audio Processing
DTS Compatibility DTS, DTS-HD High Resolution, DTS-HD Master Audio, DTS:X
Dolby Compatibility Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
Auro 3D Support No
Upmixing Technology DTS Neural:X, Dolby Atmos Height Virtualization Technology
Supported File Formats 11.2 MHz DSD, 2.8 MHz DSD, 5.6 MHz DSD, AAC, AIFF, ALAC, FLAC, MP3, WAV, WMA
DAC 384 kHz / 32-Bit (ESS SABRE ES9026PRO)
Video
HDR Compatibility HDR10, Dolby Vision, Hybrid Log Gamma
Pass-Through Support 4K60p
Upscaling None
GUI Yes
Connectivity
Rear A/V Inputs 7 x HDMI 2.1
1 x 3RCA Component
2 x RCA Composite
3 x Optical TOSLINK
2 x Digital Coaxial
1 x Stereo XLR
5 x Stereo RCA
1 x Stereo RCA (Phono) with Ground Screw
Rear A/V Outputs 3 x HDMI 2.1
1 x Stereo XLR Pre-Out
1 x 11-Channel RCA Pre-Out
1 x Stereo RCA Zone 2
1 x Stereo RCA Zone 3
2 x RCA Subwoofer
Front I/O 1 x USB Type-A
1 x 1/4" / 6.35 mm Headphone Output
1 x 1/8" / 3.5 mm Setup Mic Input
Other Rear I/O 1 x FM Antenna Terminal Input
1 x AM Antenna Terminal Input
2 x Bluetooth/Wi-Fi Antenna Terminal
2 x 1/8" / 3.5 mm (12 V Trigger) Output
1 x 1/8" / 3.5 mm (Remote) Input
1 x 1/8" / 3.5 mm (Remote) Output
1 x RJ45 (Ethernet)
Speaker Connectors 11 x Binding Post Pairs
HDCP Support Version 2.3
HDMI Compression Modes Not Specified by Manufacturer
Audio Return Channel (ARC) ARC, eARC
HDMI CEC Yes
Media Card Slot None
Bi-Amp Capability Yes
Input Impedance Phono: 47 Kilohms
RCA: 47 Kilohms
XLR: 200 Kilohms
Input Sensitivity Phono: 4.5 mV
RCA: 250 mV
XLR (Attenuator Off): 260 mV
XLR (Attenuator On): 520 mV
Rated Output / Impedance Pre-Out, Subwoofer Pre-Out: 1 V / 470 Ohms
Zone 2 Line-Out, Zone 3 Line-Out: 470 mV / 470 Ohms
Analog: 2 V / 470 Ohms
Signal to Noise Ratio Phono: 95 dB (Direct Mode / IHF-A)
Pre-Amp: 110 dB (Direct Mode / IHF-A)
Wireless Connectivity
Wi-Fi Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz)
Wireless Security AES, WEP, WPA2-PSK
Bluetooth 4.2
Bluetooth Profiles A2DP, AVRCP
Supported Audio Codecs AAC, SBC
Bluetooth Range 32.8 / 10 m
Wireless Audio Protocols AirPlay 2, MusicCast
Control
Virtual Assistant Support Amazon Alexa, Apple Siri, Google Assistant
Tuner Section
Tuner Type AM, FM
Number of Tuner Presets FM: 40 Stations
Radio Frequencies AM: 530 to 1710 kHz
FM: 87.5 to 107.9 MHz
Sensitivity FM Mono at 50 dB: 3 µV / 20.8 dBf
Signal to Noise Ratio FM:
68 dB (Stereo)
69 dB (Mono)
Power
AC Input Power 120 VAC, 60 Hz
Power Consumption Active: 500 W
CEC Standby: 1.9 W
Network Standby: 1.8 W
Bluetooth Standby: 1.7 W
Standby: 0.4 W
Physical
Dimensions (W x H x D) 17.1 x 7.6 x 17.4" / 43.5 x 19.2 x 44.2 cm
17.1 x 10.7 x 17.4" / 43.5 x 27.1 x 44.2 cm (Antenna Up)
Weight 41.2 lb / 18.7 kg
Warranty Length Limited 1-Year Warranty
