BMS 5S 18.5V 12A 18650 Li-Ion Lithium Protection Board Battery Charge Board Short Circuit Protection
Details
Discharge current: 12A
Charging current (same port): less than or equal to 10A
Main circuit conduction internal resistance: less than or equal to 20m ohm
Charging voltage: 21V
Overcharge protection
Detection voltage: 4.25 +/- 0.025V
Detection delay: 100 +/- 50Ms
Release voltage: 4.15 +/- 0.1V
Over discharge protection
Detection voltage: 2.7 +/- 0.08V
Detection delay: 100 +/- 50MS
Release voltage: 3.0 +/- 0.1V
Overcurrent protection
Detection voltage: 100MV
Detection delay: 1000MS
Current protection: 20 +/- 3A
Self-consumption
Working power consumption: less than or equal to 20UA
Sleep over discharge power consumption: less than or equal to 10UA
Working temperature range: -30/+80℃
Colour: green
Material: PCB
Size: 88x17x1.2MM
Package Contents:
1 * Battery Protection Board
