คุณสมบัติ / Specifications
คุณสมบัติ Value
FLC Motor Rating 9 → 13 A
Contact Current Rating 13 A
Pole Configuration 3P
Range TeSys
Contact Voltage Rating 690 V ac
Mounting Style Direct Contactor
Series LRD
Normal State Configuration NO/NC
Number Of Auxiliary Contacts 2
Power Rating 6 kV
Terminal Type Screw
Reset Method Automatic, Manual
Length 123mm
Depth 66mm
Width 45mm
Operating Temperature Range -20 → +60 °C
Minimum Operating Temperature -20°C
Maximum Operating Temperature +60°C
