Applications: It is used for regular room ventilation, cyclic dehumidifi cation, light control, circulating pumps, noon signs, etc.
GRT8-S1: one group groups of contacts working in a cycle at the same time
Function Features: Voltage AC230V or AC/DC12V-240V
Output 1SPDT (16A/AC1)
2 time functions: Cycler beginning with pulse,Cycler beginning with pause
Function choice is done by an external jumper of terminals S-A1.
Time scale 0.1 s - 100 days devided into 10 time ranges:
(0.1 s - 1 s / 1 s - 10 s / 0.1 min - 1 min / 1 min - 10 min / 0.1 hrs - 1 h/ 1 hrs - 10 hrs / 0.1 day - 1 day /1 day - 10 days /3 days - 30 days /10 days - 100 days).
Relay status is indicated by LED.
1-MODULE,DIN rail mounting.
Color: White
Material: PC
Package Contents:
1 x Timer Relay
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
