1) Power supply voltage: DC6.0V~30V;
2) Temperature control range: 40 ℃~110℃
3) Temperature control accuracy: 0.1
4) Measurement input: NTC10K length of 0.5 m, waterproof type, support for 18B20 digital sensor access
5) Refresh frequency: 1 second; Output type: 10A relay output (relay is equivalent to switch, only switch and cannot outputvoltage)

material: plastic
Color as shown
Product function description
2.1
Heating mode (H)
When Detect_Temperature (current temperature) Set_Temperature
Backlash _Temperature , the relay leads on and the heating equipment starts working;
When Detect_Temperature (current temperature) sets the temperature, the relay is disconnected and the heating device stops working;
Example: Set_Temperature 30 ℃, Backlash_Temperature 5
When the temperature is 20 25 (30 5 = 25), the relay suction start s to start heating, when the temperature reaches 30 Set_Temperature 30 ℃, the relay is disconnected and the heating is stopped;
2.2
Refrigeration mode (C)
When Detect_Temperature (current temperature) Set_Temperature + Backlash _Temperature , the relay is turned on and the refrigeration equipment starts working;
When Detect_Temperature (current temperature) Set_Temperature , the relay is disconnected and the refrigeration equipme nt stops working;
Example: Set_Temperature 30 ℃, Backlash_Temperature 5
When the temperature is 36 35 (30 + 5 = 35), the relay suction starts to cool, and when the temperature reaches 30 Set_Temperature 30 ℃, the relay is disconnected and the cooling is stopped

Package Contents:
1 x Temperature Controller
