OVERVIEW
A graphic equalizer with 5-band EQ that will fit on any pedal board.
The Mooer Graphic G Guitar Equalizer is the smallest guitar equalizer pedal in the world which makes it extremely handy for players with full pedal boards. Its 5-band graphic EQ with master level control lets you dial in your sound exactly how you want. It also features an ±18dB adjustable gain range per band. Its full metal casing makes it durable and road ready and like most great effects pedals it has true bypass.
FEATURES
Smallest guitar graphic equalizer pedal in the world
5-Band Graphic EQ with master level control
±18dB adjustable gain range per band
Full metal shell
Pedalboard friendly
True bypass
SPECIFICATIONS
Graphic G Guitar Equalizer Effects Pedal
Frequency Centers: 100Hz, 250Hz, 630Hz, 1.6kHz, 4kHz
Input: 1/4" monaural jack (impedance: 470k Ohms)
Output: 1/4" monaural jack (impedance: 1k Ohms)
Power Requirements: AC adapter 9V DC (center minus plug)
Current Draw: mA
Dimensions: 1.6535" (W) x 2.0472" (H) x 3.6811" (D)
Weight: 0.36lb
