1PC 908D 80W Electric Soldering Iron Heater Ceramic Internal heating element
ข้อมูลสินค้า
ราคา
410.00 205.00 บาท
แบรนด์
No Brand
ร้านค้า
- Dimensions：Lenght 70mm Diamter 3.8mm
- Output Power：60W 80W
- Temperature Stability：Adjustable
- Output Temperature：200-450
- Input Voltagle：AC 220V
- Model Number：6038-220
- Brand Name：HUXUAN
- Origin：Mainland China
- Certification：NONE
- -
- Preparation
- 1. Always keep the tip of the bit clean ensure to coat the bit liberally with solder the first time the iron is switched on. Note: Initial tinning is done in order to extend the life of the bit.
- 2. Wet the provided sponge prior to using.
- 3. Check that the solder wire is ready for use and adequately extended from the case as shown in step 1 in the above illustration below.
- 4. Ensure that the bit fits snugly and has adequate contact with the internal element.
- How to solder:
- How to change/replace bits:
- Using the soldering iron
- 1. After turning the iron on the bit will commence heating and will be ready for use when the solder wire begins to melt at contact.
- 2. Initiate soldering by ensuring the melted solder makes a clean connection between the contacts that you attempting to solder.
- 3. Move the solder wire and iron away once enough solder is placed and wipe any residual solder using the wet sponge.
- 4. Always remember to switch the iron off at the mains and place it in the provided holder while it cools enough to be stored safely.
- Notes:
- 1. Use safety goggles and take necessary precautions to avoid injury or fire.
- 2. The iron heats up quickly. Select a suitable temperature to operate at. Using the iron for long hours and at high temp may shorten the life of the product.
- 3. Make sure to only switch the iron on when required and switch it off when not in order to reduce the risk of injury and fire.
- 4. Clean the soldering tip ever so often to extend its life. Avoid using abrasive chemicals and surfaces as this could damage the metallic surface.
- 5. The provided bits are 900M series and spares are available from where you purchased this product.
-
