Nema23 Dual Shaft CNC Stepper motor 57x56 NEMA 23 stepper motor D 8mm 3A 1.26N.m double shaft stepping motor 180Oz-in
ข้อมูลสินค้า
ราคา
1,737.00 903.00 บาท
แบรนด์
No Brand
ร้านค้า
- Current / Phase：3A
- Holding Torque：1.26 N.m1.26Nm
- Step Angle(degrees)：1.8
- Phase：2
- Model Number：57HS5630B4D8
- Type：HYBRID
- Certification：ULCCCISOROHSce
- Brand Name：G-PENNY MACHINE
- Origin：Mainland China
- Size：57x57x56mm
- Voltage：2.7v
- Current：3.0A
- Resistence：0.9Ω
- Inductance：2.4mH
- Lead Wire：4
- Shaft Diameter：8
- Shaft：Double Shaft
- 1pcs -Nema23 57x56mmStepper Motor double Shaft 8mm 3.0A
- General Specification:
- Phase:2
- Step Angle:1.8 deg
- Voltage:2.7v
- Current:3.0A
- Resistence:0.90Ω
- Inductance:2.4mH
- Holding Torque:1.2Nm
- Shaft Diameter:8mm
- Double Shaft
- The magnetic steel is high gradewe usually use the SH level type.
-
- The rotor is be coatedreduce burrsworking smoothlyless noise.
- We test the stepper motor parts step by step.Stator is be test and rotor is be test before assemble.
- After we assemble the stepper motor we will do one more test for it to make sure the quality is good.
- Thisproductsarewidelyusedinengravingmachineprintermedicalequipmentembroiderymachinestagelightingtextileautomationprintingpackagingandotherindustriesautomationequipment.
