GM50H Engine Multi Function Digital Meter Generator Monitor
Details
GM50H is one light and low price-orientated module used for demonstrating engine RPM,water/oil temperature, oil pressure, battery voltage and Hours. The users can adjust and set the parameters by the button on the front face in order to meet the different requests. Besides, it uses the European-style terminals for connection which is more convenient for installation and detachment.
Various kinds of protections. Input frequency is available to check RPM
Variety of sensor curves parameters is set inside
Sensor curve can be self-defined by buttons
High-light digital tube can demonstrate the parameters. English and symbols demonstration
Specification:
Power:DC8-36V
Consumption Power:MAX:1W
Sensor Resistance:0-1000Ohm
Frequency range of RPM Input signal:Freq 300Hz~15KHz]
Amplitude range iof RPM input signal:AC3-65V
Input Power signal:AC20-280V(45-70hZ)
Input Frequency:Freq45-70Hz
Input Voltage:AC40-280V
Ingress protection:IP54
Size:100 x 100 x 77mm
Installation Size:91 x 91mm
color:Black
Material:plastic
Package Contents:
1 x Engine Multi Function Digital Meter
