The latest updated version :U8 V2.1

(13-10-2017)

Gold version ($ 72.99):The America SITIME ultra low jitter without temperature drift and low phase noise oscillator .Beijing green cube transformer .

Black version ($ 92.99 ): Using 2pcs ultra high precision 0.1PPM gold plated low phase noise oscillator . Beijing green cu be transformer .

Silver version ($ 108.99):Using 2pcs ultra high precision 0.1PPM gold plated low phase noise oscillator . Imported TAEMA transformer .

USB audio XMOS asynchronous receiver scheme, is one of the most outstanding asynchronous USB audio program. By the vast number of high-end manufacturers used, almost became the standard of USB audio high end applications.

Product features:

*XMOS-XU208 core,(Increase the EMI power filter)the latest program, the highest support 384khz 32B asynchronous transfer.

New XMOS U8 (V2.1)upgrade edition interface, using the second generation XMOS XU208 development of USB interface chip, also support firmware upgrade interface.Schematic diagram and the firmware (including XMOS and CPLD) are our self-developed, not a generic version

*Built in imported TALEMA sealed transformer(sliver version), the use of top linear regulators chip, multi-level multi group independent power supply, more than a few hundred dollars on the market XMOS linear power supply, the only one in the whole network to use such a high-end power XMOS decoding, the advantages of independent power supply experts know, even if the external power supply, circuit design is not fully independent regulator is no effect.

*The optimization and upgrading of the clock circuit, 44.1/88.2/176.4/352.8Khz and 48/96/192/384Khz respectively using two crystal

*The output interface is complete, with the current mainstream of all interface to improve the ability to play

• Input:USB data line

• output:coaxial,optical,IIS(RJ45),AES/EBU

• support:16bit 24bit 32bit

• Windows /MAC/ PCM : 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz(coaxial,optical,AES the hightest support 192K, if it is above 192K,it needs to be used with IIS transfer)

• DSD: DSD64 , DSD128, DSD256(2.822, 3.072, 5.644, 6.144, 11.2896 and 12.288MHz)(DSD needs to
  be used with IIS transfer and the support of DAC

• Packing list: U8 1pcs,USB line 1pcs.

  (Do not include power lines, please prepare by yourself)

Black Version:

Packing list: U8 1pcs,USB line 1pcs.

(Do not include power lines, please prepare by yourself)
