Feature:
1. [Video Audio Converter] Convert HD and 3G SDI to composite video and stereo audio.Specification:
Item Type: 3G SDI to AV Converter
Material: Metal
Model: F001
Colour: Black
Function: Digital Information Conversion
SMPTE Standard: 425M class A&B 424M 292M 259M-C
SDI Transmission Rate: 2,970 Gbit/s and 2,970 / 1,001 Gbit/s
SDI Input Output Resolution: 480i at 60, 576i at 50
HD Resolution: 720p at 50/60,1080i at 50/60
3G Resolution: 1080p at 24/25/29/97/30/50/59/94/60
Input Port: 1 BNC (/HD/3G-SDI)
Output Port: 1 x BNC (HD/3G-SDI) 3 xRCA (CVBS L/R)
Input Voltage: DC 5V
Working Temperature: 0°C~40°C/32°F~104°F
Power Consumption: 5W (maximum)
Package List:
1 x 3G SDI to AV Converter
1 x Power Adapter
1 x Manual
